Industrial 300W-1500W Cabinet Air Conditioner | R134a Hitachi Compressor for CNC Machine Tools

Industrial cabinet air conditioner 300W, 400W, 600W, 800W, 1500W with R134a refrigerant and Hitachi compressor, IP34 protection, suitable for CNC machine tools, electrical cabinets and automation equipment.

Our industrial cabinet air conditioner series is specially designed for cooling electrical cabinets, PLC control cabinets, automation equipment, and CNC machine tool cabinets. Equipped with reliable Hitachi compressors and environmentally friendly R134a refrigerant, it provides stable and efficient cooling performance. With IP33/IP34 protection, wide temperature resistance, low noise, and energy-saving operation, it ensures long-term stable running in harsh industrial environments. Multiple installation methods and full customization are available to meet different application requirements.

product details

product description

description1

description2

Key Features

Equipped with high-performance Hitachi compressor for strong cooling and long service life

Cooling capacity options: 300W, 400W, 600W, 800W, 1000W, 1500W, 2500W

Adopts eco-friendly R134a refrigerant for safe and efficient cooling

IP33 / IP34 protection grade, dustproof and splash-proof

Precise temperature control: digital display or mechanical thermostat

Fast cooling and effective dehumidification to protect electrical components

Rugged carbon steel construction; optional stainless steel for corrosive environments

Multiple mounting types: side-mounted, top-mounted, built-in

Low noise, low energy consumption, stable operation

Customizable power, dimensions, color and material

2-year manufacturer warranty and strict quality control

Technical Specifications (EA Series)

Item	Details
Brand	Shanghai Sheyu Industrial
Product Name	Outdoor Industrial Cabinet Air Conditioner
Cooling Capacity	300W, 450W, 600W, 1000W, 1500W, 2500W
Power Supply	AC 220V 50Hz
Protection Grade	IP33 / IP34
Refrigerant	R134a / R22
Temperature Control	Digital display / mechanical thermostat
Cabinet Temp Range	25–38°C
Ambient Temp Range	-5°C ~ 43°C
Material	Carbon steel; optional stainless steel
Color	RAL 7035 light gray
Noise	55–70 dB
Mounting	Side-mounted, top-mounted, built-in
Warranty	2 years

Dimension & Performance Table

Model	W×H×D (mm)	Cooling Power	Current	Net Weight
EA-300	286×445×173	300W	1.2A	15kg
EA-450/500	286×500×173	450W	1.5A	17kg
EA-600/800	350×630×203	600W	2.1A	26kg
EA-1000	360×745×220	1000W	2.85A	32kg
EA-1500	370×855×231	1500W	3.7A	37kg
EA-2500	435×1160×275	2500W	6.3A	60kg

Applications

Industrial PLC & automation control cabinets

Outdoor electrical power distribution cabinets

Telecom base station & communication cabinets

Battery cabinets & energy storage equipment

Factory electrical cabinets & machinery control panels

Outdoor integrated equipment shelters

Harsh environment cooling for industrial sites

CNC machine tool electrical cabinets

Why Choose Us

✔ Reliable Hitachi compressors for stable performance

✔ IP34 protected for dust & splash resistance

✔ Outdoor high-temperature design (-5°C to 43°C)

✔ Multiple mounting: side, top, built-in

✔ Custom power, size, material & color available

✔ 2-year warranty & strict quality control

✔ Energy saving, low noise, long service life

✔ Fast delivery & nationwide after-sales support

Product Highlights

1. Heavy-Duty Casing

Carbon steel structure with durable coating; optional stainless steel for corrosive environments.

2. Digital Display Controller

Clear LED readout for real-time temperature monitoring and precise adjustment.

3. Strong & Stable Cooling

Efficient heat dissipation, sealed internal circulation to block dust and moisture.

4. Flexible Installation

Adapt to different cabinet structures with multiple mounting solutions.

FAQ

Q: What cabinets is this air conditioner suitable for?

It fits all kinds of sealed electrical cabinets, PLC control cabinets, power distribution cabinets, telecom cabinets, battery cabinets, and outdoor industrial enclosures.

Q: Can it work in high outdoor temperatures?

Yes. Designed for outdoor use, it operates stably in ambient temperatures from -5°C up to 43°C.

Q: Do you provide custom solutions?

Yes. We customize cooling capacity, dimensions, materials (stainless steel optional), colors, and mounting types.

Q: What is the warranty period?

We provide a 2-year manufacturer warranty for all our cabinet air conditioners.

Q: What installation methods are available?

Side-mounted, top-mounted, and built-in styles to match different cabinet structures.
