New CE Certified Outdoor Split Wall-Mounted Industrial Air Conditioner 500W 220V R134a

This new CE-certified outdoor split wall-mounted industrial air conditioner is specifically designed for cooling sealed electrical enclosures in harsh outdoor environments. With 500W cooling capacity, AC 220V power supply, and R134a eco-friendly refrigerant, it is equipped with a high-efficiency pump and motor to deliver strong, stable cooling performance. Featuring low noise, energy-saving operation, and wall-mounted split design, it is widely applicable to industrial PLC & automation control cabinets, outdoor power distribution cabinets, telecom base stations, battery cabinets, and energy storage equipment. It operates stably in ambient temperatures from -5°C to 43°C, with strict quality control and comprehensive after-sales support.

product details

product description

description1

description2

Key Features

CE Certified, complying with EU safety standards for reliable quality

Outdoor split wall-mounted design, flexible installation and higher heat dissipation efficiency

500W cooling capacity, AC 220V 50Hz power supply, perfectly adapted to industrial scenarios

R134a eco-friendly refrigerant, green, safe and stable in cooling

Equipped with dedicated pump and motor, providing sufficient power and long service life

High protection grade (IP33/IP34), dustproof and splash-proof, suitable for harsh outdoor environments

Precise temperature control, maintaining constant temperature and dryness inside the cabinet

Low noise, low energy consumption and stable operation

Sturdy structure, corrosion-resistant and anti-aging

Support bulk customization, factory direct supply with worry-free warranty

Technical Specifications (EA Series)

Item	Details
Product Name	Outdoor Industrial Cabinet Air Conditioner
Cooling Capacity	300W, 450W, 600W, 1000W, 1500W, 2500W
Power Supply	AC 220V 50Hz
Protection Grade	IP33 / IP34
Refrigerant	R134a / R22
Temperature Control	Digital display / mechanical thermostat
Cabinet Temp Range	25–38°C
Ambient Temp Range	-5°C ~ 43°C
Material	Carbon steel; optional stainless steel
Color	RAL 7035 light gray
Noise	55–70 dB
Mounting	Side-mounted, top-mounted, built-in, wall-mounted
Certification	CE
Warranty	2 years

Dimension & Performance Table

Model	W×H×D (mm)	Cooling Power	Current	Net Weight
EA-300	286×445×173	300W	1.2A	15kg
EA-450/500	286×500×173	450W/500W	1.5A	17kg
EA-600/800	350×630×203	600W	2.1A	26kg
EA-1000	360×745×220	1100W	2.85A	32kg
EA-1500	370×855×231	1500W	3.7A	37kg
EA-2500	435×1160×275	2500W	6.3A	60kg

Applications

Industrial PLC & automation control cabinets

Outdoor electrical power distribution cabinets

Telecom base station & communication cabinets

Battery cabinets & energy storage equipment

Factory electrical cabinets & machinery control panels

Outdoor integrated equipment shelters

Harsh environment cooling for industrial sites

Why Choose Us

✔ Reliable Hitachi compressors for stable performance

✔ IP34 protected for dust & splash resistance

✔ Outdoor high-temperature design (-5°C to 43°C)

✔ Multiple mounting: side, top, built-in, wall-mounted

✔ Custom power, size, material & color available

✔ 2-year warranty & strict quality control

✔ Energy saving, low noise, long service life

✔ Fast delivery & nationwide after-sales support

Product Highlights

1. Heavy-Duty Casing

Carbon steel structure with durable coating; optional stainless steel for corrosive environments.

2. Digital Display Controller

Clear LED readout for real-time temperature monitoring and precise adjustment.

3. Strong & Stable Cooling

Efficient heat dissipation, sealed internal circulation to block dust and moisture.

4. Flexible Installation

Adapt to different cabinet structures with multiple mounting solutions (side-mounted, top-mounted, built-in, wall-mounted).

FAQ

Q: What cabinets is this air conditioner suitable for?

It fits all kinds of sealed electrical cabinets, PLC control cabinets, power distribution cabinets, telecom cabinets, battery cabinets, and outdoor industrial enclosures.

Q: Can it work in high outdoor temperatures?

Yes. Designed for outdoor use, it operates stably in ambient temperatures from -5°C up to 43°C.

Q: Do you provide custom solutions?

Yes. We customize cooling capacity, dimensions, materials (stainless steel optional), colors, and mounting types.

Q: What is the warranty period?

We provide a 2-year manufacturer warranty for all our cabinet air conditioners.

Q: What installation methods are available?

Side-mounted, top-mounted, and built-in styles to match different cabinet structures.
